| P/N | PS-SPD-0500MNSABU-1 |
|---|---|
| WATTS | 500W |
| RGB FAN | No |
| MODEL | SPD-0500AH3CKB |
| TYPE | ATX 12V v2.3 and EPS v2.92 |
| MAX. OUTPUT CAPACITY | 500W |
| PEAK OUTPUT CAPACITY | 600W |
| COLOR | Black |
| DIMENSION ( W / H / D ) | 150mm(W) x 86mm(H) x 160mm(D) |
| PFC (POWER FACTOR CORRECTION) | Active PFC |
| POWER GOOD SIGNAL | 100-500 msec |
| HOLD UP TIME | > 16msec at 80% of full load |
| INPUT CURRENT | 5A |
| INPUT FREQUENCY RANGE | 50Hz |
| INPUT VOLTAGE | 230V |
| OPERATING TEMPERATURE | 5°C to + 35°C |
| OPERATING HUMIDITY | 20% to 85%, non-condensing |
| STORAGE TEMPERATURE | -40°C to + 55°C |
| STORAGE HUMIDITY | 10% to 95%, non-condensing |
| COOLING SYSTEM | 14cm fan |
| EFFICIENCY | Meet 80 PLUS®Bronze 230V EU Certified |
| MTBF | 100,000 hrs minimum |
| SAFETY APPROVAL | CE, CB, TUV, EAC, RCM |
| PCI-E 6+2PIN | 2 |
