| CPU | AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors |
| Chipset | B550 |
| Memory | 4 x DIMM, Max. 128GB, DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133, Un-buffered Memory* |
| Dual Channel Memory Architecture | |
| Graphics | 1 x DisplayPort |
| 1 x HDMI port | |
| Expansion Slots | AMD Ryzen 5000 Series/ 3000 Series Desktop Processors |
| 1 x PCIe 4.0 x16 slot (supports x16 mode) | |
| AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors | |
| 1 x PCIe 3.0 x16 slot (supports x16 mode) | |
| AMD B550 Chipset | |
| 1 x PCIe 3.0 x16 slot (supports x4 mode) | |
| 1 x PCIe 3.0 x1 slot | |
| Storage | Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports |
| AMD Ryzen邃｢ 5000 Series/ 3000 Series Desktop Processors | |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) | |
| AMD Ryzen邃｢ 5000 G-Series/ 4000 G-Series Desktop Processors | |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) | |
| AMD B550 Chipset | |
| M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes) | |
| 4 x SATA 6Gb/s ports | |
| Support RAID 0, 1, 10 | |
| Ethernet | TUF LANGuard |
| Wireless & Bluetooth | 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT5.2 |
| USB | Rear USB:Total 8 ports |
| 2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C庐) | |
| 4 x USB 3.2 Gen 1 ports (4 x Type-A) | |
| 2 x USB 2.0 ports (2 x Type-A) | |
| Front USB:Total 6 ports | |
| 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports | |
| 2 x USB 2.0 headers support additional 4 USB 2.0 ports | |
| Form Factor | microATX |
| 24.4cm x 24.4cm |
