| CPU | AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* |
| Chipset | AMD B650 |
| Memory | 2 x DIMM, Max. 96GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 ECC and Non-ECC, Un-buffered Memory |
| Dual Channel Memory Architecture | |
| Supports AMD EXTended Profiles for Overclocking (EXPO™) | |
| OptiMem II | |
| Graphics | 1 x HDMI® port*** |
| 1 x USB3.2 Gen2 port supports USB Type-C® display outputs**** | |
| Expansion Slots | 1 x PCIe 5.0 x16 slot* |
| Storage | Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports* |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) | |
| M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) | |
| 2 x SATA 6Gb/s ports | |
| Ethernet | 1 x Intel® 2.5Gb Ethernet |
| ASUS LANGuard | |
| Wireless & Bluetooth | Wi-Fi 6E |
| 2×2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) | |
| Bluetooth® v5.2** | |
| USB | Rear USB (Total 8 ports) |
| 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®) | |
| 5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C®) | |
| 2 x USB 2.0 ports (2 x Type-A) | |
| Front USB (Total 5 ports) | |
| 1 x USB 3.2 Gen 2 connector | |
| 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports | |
| 1 x USB 2.0 header supports additional 2 USB 2.0 ports | |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Impedance sense for front and rear headphone outputs | |
| Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking | |
| High quality 120 dB SNR stereo playback output and 113 dB SNR recording input | |
| Supports up to 32-Bit/384 kHz playback | |
| Back Panel I/O Ports | 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®) |
| 5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C® with DP Alt mode) | |
| 2 x USB 2.0 ports (2 x Type-A) | |
| 1 x HDMI® port | |
| 1 x Wi-Fi Module | |
| 1 x Intel® 2.5Gb Ethernet port | |
| 3 x LED-illuminated audio jacks | |
| 1 x Optical S/PDIF out port | |
| 1 x BIOS FlashBack™ button | |
| 1 x FlexKey button | |
| Internal I/O Connectors | Fan and Cooling related |
| 1 x 4-pin CPU Fan header | |
| 1 x 4-pin AIO Pump header | |
| 1 x 4-pin Chassis Fan header | |
| Power related | |
| 1 x 24-pin Main Power connector | |
| 1 x 8-pin +12V Power connector | |
| Storage related | |
| 2 x M.2 slots (Key M) | |
| 2 x SATA 6Gb/s ports | |
| USB | |
| 1 x USB 3.2 Gen 2 connector | |
| 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports | |
| 1 x USB 2.0 headers supports additional 2 USB 2.0 ports | |
| Miscellaneous | 1 x Addressable Gen 2 header |
| 1 x AURA RGB header | |
| 1 x Clear CMOS header | |
| 1 x CPU Over Voltage jumper | |
| 1 x 12-1 pin Front Panel Audio header (AAFP) | |
| 1 x 10-1 pin System Panel header | |
| 1 x Speaker header | |
| 1 x Thermal Sensor header | |
| Special Features | Extreme Engine Digi+ |
| ASUS Q-Design | |
| ASUS Thermal Solution | |
| ASUS EZ DIY | |
| AURA Sync | |
| Software Features | ROG Exclusive Software |
| ASUS Exclusive Software | |
| UEFI BIOS | |
| Manageability | WOL by PME, PXE |
| Accessories | Cables |
| Additional Cooling Kit | |
| Miscellaneous | |
| Documentation | |
| Operating System | Windows® 11 64-bit, Windows 10 64-bit |
| Form Factor | Mini-ITX Form Factor |
| 6.7 inch x 6.7 inch (17 cm x 17 cm) |
motherboard, PRE ORDER
ASUS MB ROG STRIX B650E-I GAMING WIFI
₱20,650.00
- AM5
- AMD Ryzen™ 7000 Series
- AMD B650
- 2 x DIMM, Max.64GB, DDR5
- 1 x M.2 2242/2260/2280 (PCIe 5.0 x4)
1 x M.2 2242/2260/2280 (PCIe 4.0 x4) - 1 x USB 3.2 Gen 2×2
6 x USB 3.2 Gen 2
2 x USB 3.2 Gen 1
4 x USB 2.0 - 2 x SATA 6Gb/s cables
1 x Thermal pad for M.2 - Wi-Fi 6E
- 1 x Intel® 2.5Gb
- Dynamic OC Switcher, PBO, Core Flex
- Mini-ITX
